Presa EFB Elektronik 29563.1

The EFB Elektronik 29563.1 Socket-outlet is a full metal cover coaxial outlet with a 35° cable outlet and a silver zinc finish. Designed for reliable signal transmission, this socket-outlet provides 40 dB attenuation to reduce interference and maintain signal quality in installations requiring a robust metal housing.

Advantages

The zinc full-metal construction offers mechanical durability and shielding against electromagnetic interference. A 35° cable outlet orientation facilitates cable routing in tight spaces. The 40 dB attenuation ensures effective suppression of unwanted signals while preserving the desired transmission characteristics.

Suitable for

• Home and commercial TV/RF installations
• Set-top boxes and satellite receivers
• Wall-mounted cable routing where a low-profile angled outlet is needed

Key specifications

• Manufacturer: EFB Elektronik
• Model / MPN: 29563.1
• EAN: 4049759066413
• Material: Zinc (full metal cover)
• Color/Finish: Silver
• Cable outlet angle: 35°
• Attenuation: 40 dB

How to use

Mount the socket-outlet in a standard flush wall box and connect the coaxial cable to the angled outlet, ensuring a secure threaded or push-fit connection depending on the cable connector type. Verify the orientation so the 35° outlet aligns with the intended cable routing path, then test the signal to confirm correct installation and adequate attenuation.

Recommendations

Use this zinc full-metal socket-outlet in environments where mechanical robustness and EMI shielding are required; avoid installing in corrosive environments without appropriate protection and ensure compatible connector types for optimal performance.
