SIEMENS 5SV33224 interruttore differenziale, tipo B, 25 A, 30 mA, 230 V, 1+N, 4 TE, a ritardo breve

This SIEMENS residual current circuit breaker stands out with its Type B tripping characteristic, which detects smooth DC residual currents in addition to AC and pulsating DC, making it suitable for circuits with frequency converters or EV charging. The short-time delayed version avoids nuisance tripping from brief current spikes.

Highlights

• Type B RCCB for comprehensive protection against AC, pulsating DC, and smooth DC residual currents
• Rated residual current 30 mA for personal protection
• Short-time delayed tripping to prevent false trips from transient surges
• Compact 4 TE width for space-saving DIN rail installation

In daily use

Install this 2-pole (1+N) RCCB on a DIN rail to protect a 230 V single-phase circuit. It handles rated currents up to 25 A and interrupts residual currents of 30 mA. The screw terminals accept solid conductors from 0.75 to 35 mm² and stranded from 0.75 to 25 mm², ensuring flexible wiring options.

Full specifications

• Product type: Residual Current Circuit Breaker (RCCB)
• Number of poles: 2 (1+N)
• Rated current (In): 25 A
• Rated residual current (IΔn): 30 mA
• Rated voltage (Un): 230 V AC
• RCD type: Type B
• Tripping characteristic: Short-time delayed
• Rated frequency: 50/60 Hz
• Rated switching capacity (Icn): 10 kA
• Surge current withstand capability: 3 kA (8/20 µs)
• Module width: 4 TE (72 mm)
• Mounting type: DIN rail (EN 60715)
• Degree of protection: IP20 (terminals), IP40 (with enclosure)
• Operating temperature range: -25 °C to +45 °C
• Storage temperature range: -40 °C to +75 °C
• Terminal type: Screw terminals
• Terminal capacity (solid): 0.75 ... 35 mm²
• Terminal capacity (stranded): 0.75 ... 25 mm²
• Rated impulse withstand voltage (Uimp): 4 kV
• Electrical endurance: 10,000 switching cycles

Final note

Engineered for demanding applications where DC fault currents may occur, this RCCB provides reliable protection and operational stability.
