WAGO 821-507 modulo relè di interfaccia, 24 V DC, 1 scambio, Push-in CAGE CLAMP, conforme Westnetz

Interface relay module with 1 changeover contact, engineered for reliable signal adaptation and isolation in industrial control systems. Its 24 V DC coil and push-in CAGE CLAMP® terminals enable fast, tool-free wiring, while the Westnetz-specific approval ensures compliance with German energy sector regulations (EnWG).

Advantages

Compact DIN-rail mountable design saves panel space. Push-in CAGE CLAMP® technology reduces installation time by up to 50% compared to screw terminals. LED status indication provides immediate visual feedback on coil energization. High dielectric strength of 4 kV between coil and contacts enhances safety in mixed-voltage environments. Silver nickel (AgNi) contacts offer excellent conductivity and long service life.

Suitable for

• Signal conditioning and galvanic isolation in PLC and DCS systems
• Interfacing between low-power control circuits and higher-power loads
• Applications requiring compliance with Westnetz specifications under German EnWG
• Industrial automation, building technology, and energy distribution

Key specifications

• Coil voltage: 24 V DC
• Contact configuration: 1 changeover (1 C/O)
• Max switching capacity: 6 A / 250 V AC, 6 A / 30 V DC
• Connection: Push-in CAGE CLAMP®, 6 connection points
• Mounting: DIN-rail 35 mm
• Operating temperature: -25 °C to +70 °C
• Protection degree: IP20
• Approvals: VDE, UL, CSA, GL, Westnetz-specific

Recommendations

For reliable signal interfacing in energy and industrial applications, the WAGO 821-507 combines proven relay technology with Westnetz compliance, ensuring safe and efficient operation in demanding environments.
