BlueOptics MCP7F00-A01A-BL cavo Direct Attach Copper QSFP28 2 m passivo 100 Gb/s InfiniBand EDR 100GbE nero

The BlueOptics MCP7F00-A01A-BL is a high-performance QSFP28 Direct Attach Copper (DAC) cable designed for data centers and high-performance computing environments. With a length of 2 meters and passive construction, it delivers reliable 100 Gb/s connectivity for InfiniBand EDR and 100 Gigabit Ethernet networks. This cable is compatible with Mellanox/NVIDIA MCP7F00 series equipment and features a durable PVC jacket with 30 AWG gauge for optimal signal integrity.

Advantages

Cost-effective and low-latency solution for short-range high-speed interconnects. Passive design ensures zero power consumption and minimal heat generation. Pre-terminated QSFP28 connectors guarantee quick deployment and reliable performance.

Suitable for

• Data center top-of-rack to server connections
• High-performance computing clusters
• Enterprise networking with 100GbE or InfiniBand EDR

Key specifications

• Cable Type: Direct Attach Copper (DAC)
• Connectors: QSFP28 to QSFP28
• Data Rate: 100 Gb/s
• Protocols: InfiniBand EDR, 100 Gigabit Ethernet
• Length: 2 m
• Color: Black
• AWG: 30
• Jacket Material: PVC
• Passive
• Impedance: 100 Ohm
• Operating Temperature: 0 to 70 °C
• Compliance: RoHS, CE, FCC

Recommendations

Ideal for short-distance, high-bandwidth links within racks. Ensure compatibility with your switch or NIC ports (QSFP28). For longer distances, consider active optical cables.
