EXERTIS CONNECT Cat.6 S/FTP PiMF cavo patch, bianco, 15 m 856923

Long network runs often suffer from crosstalk and interference, especially in dense cable trays or near power lines. This 15-metre patch cable solves that with double shielding: an overall braid plus foil around each wire pair, ensuring clean Gigabit Ethernet even over longer distances.

Who is it for

IT technicians, office installers, and home users who need a reliable, long patch cable for connecting devices across rooms or between patch panels and switches.

Main features

• S/FTP shielding: braided screen plus foil per pair for maximum interference rejection
• PiMF (Pairs in Metal Foil) construction reduces alien crosstalk
• CAT.6 performance supports up to 250 MHz bandwidth and 1 Gbps data transfer
• Slim, snagless boot protects the locking tab and eases routing in tight spaces
• LSZH jacket: low smoke and halogen-free for safer indoor use
• Gold-plated RJ45 contacts resist corrosion and ensure reliable connections

Specifications

• Cable length: 15 m
• Category: CAT.6
• Shielding: S/FTP (Screened/Foiled Twisted Pair)
• Conductor shielding: PiMF (Pairs in Metal Foil)
• Connector type: RJ45 male to RJ45 male
• Connector plating: Gold-plated contacts
• Conductor material: Copper
• Conductor gauge: AWG 27/7 (stranded)
• Jacket material: LSZH (Low Smoke Zero Halogen)
• Bend protection: Slim/snagless boot
• Wiring scheme: 1:1 (straight-through)
• Bandwidth: Up to 250 MHz
• Data transfer rate: Up to 1000 Mbps (Gigabit Ethernet)
• Standards compliance: ISO/IEC 11801, EN 50173, TIA/EIA 568-B.2-1
• Halogen-free: Yes
• Application: Ethernet, LAN, Network
• Operating temperature: -20°C to +60°C
• Outer diameter: Approx. 6.0 mm

Tips

For best performance, avoid sharp bends and keep the cable away from high-voltage power lines. The slim boot design allows easy removal from densely populated patch panels.
