METZ CONNECT pannello di permutazione 19 pollici, 0,5HE, 56 mm, RAL 9005 nero (130894-05-29-E)

The METZ CONNECT 130894-05-29-E is a high-quality 19-inch patch panel designed for professional fiber optic network infrastructure. With 24 LC-Duplex ports in a compact 1U form factor, it supports multimode OM4 fiber and features a robust steel construction with a jet black powder-coated finish (RAL 9005). Ideal for data centers, server rooms, and enterprise networks, this panel ensures reliable performance and easy cable management.

Advantages

Space-saving 1U design maximizes rack utilization. Ceramic sleeve adapters provide low insertion loss (<0.2 dB) and high return loss (>30 dB) for optimal signal integrity. Rear cable entry and included cable ties simplify organization. Splice tray support allows integration of splice cassettes for field termination.

Suitable for

• Data centers requiring high-density fiber patching
• Server rooms with structured cabling
• Enterprise networks needing reliable OM4 connectivity
• Telecommunications and IT infrastructure

Key specifications

• Mounting: 19-inch rack, 1U
• Ports: 24x LC-Duplex
• Fiber type: Multimode OM4
• Adapter: LC-Duplex, ceramic sleeve
• Colour: Black (RAL 9005)
• Material: Steel, powder-coated
• Operating temperature: -10 to +60 °C
• Standards: IEC 61753-1, TIA/EIA-568.3-D
• Insertion loss: <0.2 dB
• Return loss: >30 dB

Recommendations

For optimal performance, use with OM4 patch cables and ensure proper cable management. Compatible with standard 19-inch racks and splice cassettes.
