Cavo in fibra ottica InfiniBand BlueOptics SFP3132EU10MK 10 m LC aqua

The BlueOptics SFP3132EU10MK InfiniBand fibre optic cable is a 10 m duplex patch cord with LC connectors and OM3 multimode fibre (50 µm core). Designed for 850 nm transmission, this Aqua-coloured cable supports full duplex data transfer and is suitable for connections between patch panels, optical transceivers and network equipment where InfiniBand or multimode fibre links are required. The cable features a flame-retardant LSZH jacket for reduced smoke emission and no halogen release in case of fire.

Advantages

This OM3 multimode cable provides low attenuation (approximately 3.5 dB/km) and low insertion loss with high return loss. Connectors use zirconia ceramic ferrules from reputable manufacturers to ensure reliable mating and durability up to industry-standard mating cycles. Each cable is tested with interferometry and OTDR methods and is delivered with measurement results for input loss and return loss, ensuring consistent, error-free signal transmission. The LSZH jacket improves safety in confined spaces compared with PVC jackets.

Suitable for

Key specifications

How to use

Route the BlueOptics SFP3132EU10MK cable between the two intended optical ports, ensuring connector orientation matches the equipment ports and that connector clips are fully engaged. Avoid tight bends and excessive tensile load on the cable; maintain the manufacturer’s minimum bend radius and secure the cable along its path to prevent strain. Clean connector endfaces before making connections and follow standard ESD and fibre-handling precautions when installing or removing the cable.

Recommendations

Use this OM3 LC duplex patch cord for short-range multimode links up to the distances supported by 850 nm OM3 specifications; verify transceiver compatibility and port types before installation. Store and handle connectors in protective caps when not in use and follow regular inspection and cleaning procedures to maintain low insertion loss and reliable performance.
