Telegärtner H02082A0016 cavo breakout in fibra ottica 75 m LC duplex su 4x LC duplex OM4 LSZH Heather Violet

The Telegärtner H02082A0016 is a high-performance fiber optic breakout cable designed for reliable data transmission in demanding network environments. With a length of 75 meters and LC-Duplex to 4x LC-Duplex connectivity, this cable supports multimode OM4 fiber for high-bandwidth applications up to 100G Ethernet.

Advantages

This breakout cable offers exceptional signal integrity with low insertion loss (≤0.25 dB per connector) and high return loss (≥30 dB). The LSZH (Low Smoke Zero Halogen) jacket ensures safety in confined spaces, while the heather violet color aids easy identification. OM4 fiber provides superior bandwidth and distance performance for 10G, 40G, and 100G networks.

Suitable for

• Data center interconnects
• High-speed enterprise networks
• Telecommunications infrastructure
• Fiber-to-the-desk applications

Key specifications

• Cable Type: Fiber Optic Breakout Cable
• Connector A: LC-Duplex
• Connector B: 4x LC-Duplex
• Fiber Type: Multimode OM4
• Number of Fibers: 8
• Cable Length: 75 m
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Jacket Color: Heather Violet
• Core/Cladding Diameter: 50/125 µm
• Connector Polishing: UPC (Ultra Physical Contact)
• Insertion Loss: ≤0.25 dB per connector
• Return Loss: ≥30 dB
• Operating Temperature: -10 °C to +60 °C
• Storage Temperature: -20 °C to +70 °C
• Attenuation (850 nm): ≤2.3 dB/km
• Attenuation (1300 nm): ≤0.6 dB/km
• Bandwidth (850 nm): 4700 MHz*km
• Bandwidth (1300 nm): 500 MHz*km

Recommendations

For optimal performance, pair this cable with compatible OM4 transceivers and ensure proper handling to maintain low insertion loss. Ideal for structured cabling in data centers and enterprise networks.
